5 HP Outboard Motor

You want power. You want performance. You want portability. You want Calon Gloria.


Calon Gloria 5 hp outboard would make a great outboard motor for any small watercraft such as a small sailboat, kicker dingy, jon boat, canoe, inflatable, portable boat, water tender skiff, or any other watercraft need that can accommodate a 36lbs. 2-stroke 20" short Shaft outboard motor.


Specifications

Overview

CalonGloria 2-stroke benefits

●Excellent reliability with proven 2-stroke technology

●Simple in design


Easy operation and handling

●Loop charged induction for smooth operation and fuel economy

●CD ignition system for quicker starts,Light weight and easy to transport


Fundamentals for user convenience and reliability

●Through-the-prop exhaust for a quiet ride

●Thermostatically controlled cooling system for consistent engine temperature

●Stainless steel water pump housing for outstanding durability

●High grade marine aluminum alloy that provides the ultimate protection against corrosion

●Zinc coating on internal water passages for superior corrosion resistance

●Aluminum propeller

●Hour metering for easy maintenance record.


Protection

●Safety lanyard (an essential protection feature standard on all CalonGloria outboards)

●Start-in-gear protection for safer engine starting


AVAILABLE MODELS: T5BS - Manual Start, Tiller Handle, Transom height - Standard


Specifications

Type
Two Stroke
Maximum output
5hp (3.7kw)
DimensionsmmS: 677*322*978
L: 677*322*1011
WeightkgS: 20.5
L: 21
Maximum operating rangerpm4500-5500
Gear Oil quantityL0.1
Number of cylinder
1
Bore x Strokemm54.0 x 45.0
Displacementcm³103
Option
12V-40W,60W
Cooling system
Water/Thermostatic Control
Starting system
Choke valve
Ignition
CDI
Spark plug
NGK BR7HS-10
Idel speedrpm/min1150±50
Spark plug gapmm0.6-0.7
Engine oil
Genuine recommended 2 stroke engine oil
Oil Ratio Fuel Mixture :
50:1
Fuel tank sizeL2.8/12
Speed control
Twist grip type
Gear ratio
2.08 (27:13)
Gear Shift
F-N Shift


5 HP Outboard Motor


5 HP Outboard Motor

5 HP Outboard Motor

5 HP Outboard Motor


Please consult to your local distributor if any questions.

▲Due to CalonGloria’s ongoing commitment to product improvement, we reserve the right to change without notice, equipment, materials, or specifications.
